Category Archives: Blogs

What Is Gear Contact Ratio and Why Does It Matter?

What Is Gear Contact Ratio and Why Does It Matter

Two gears can rotate normally and still have less-than-ideal meshing conditions. Besides module, tooth count, pressure angle, center distance and tooth form, gear contact ratio is another important parameter for evaluating whether a gear pair can transmit motion continuously and smoothly. In simple terms, contact ratio describes how many pairs of teeth are involved in transmitting […]

What Is Gear Pressure Angle? 14.5° vs 20° vs 25°

What Is Gear Pressure Angle 14.5° vs 20° vs 25°

On gear drawings, pressure angle values such as 14.5°, 20°, and 25° often appear alongside module, tooth count, and other basic geometry. Although it looks like a simple angle, it affects the tooth profile, meshing behavior, tooth-root strength, and load direction within a gear pair. Among modern involute gears, 20° is widely used as a standard […]

Cylindrical Gear vs Bevel Gear: How to Choose the Right Type?

Cylindrical Gear vs Bevel Gear How to Choose the Right Type

Introduction A cylindrical gear vs bevel gear comparison starts with the shaft layout. If the shafts are parallel, spur or helical gears are usually the starting point. If their axes intersect, bevel gears may suit the drive. The next question is whether that arrangement can handle the load within the available space. For buyers working […]

Hypoid Gear Offset: How Does It Affect Performance?

Hypoid Gear Offset How Does It Affect Performance

Introduction A hypoid gear set differs from a conventional bevel gear in one important way: the pinion axis and gear axis do not intersect. The shortest distance between those axes is the hypoid gear offset. It may look like a simple layout dimension, but it influences pinion geometry, tooth contact, sliding, lubrication, and the final […]

Ground Spiral Bevel Gears: When Is Grinding Worth It?

Ground Spiral Bevel Gears When Is Grinding Worth It

Introduction Ground spiral bevel gears are not necessary for every application. In many industrial drives, a properly cut, heat-treated, and lapped gear set can already meet the required accuracy, contact, and running performance. At Wenlio, the finishing route is selected according to the actual gear and application requirements. Grinding becomes more valuable when tighter post-heat-treatment […]

Bevel Gear Supplier: What to Check Before an RFQ?

Bevel Gear Supplier What to Check Before an RFQ

Introduction Not every bevel gear supplier is a good fit for every project. A company that can produce a standard straight bevel gear may not necessarily be the right choice for a spiral bevel, hypoid, or matched-pair project with defined contact and inspection requirements. Before sending an RFQ, it helps to check whether the supplier’s […]

Spiral Bevel Gear Noise: What Should You Check First?

Spiral Bevel Gear Noise What Should You Check First

Introduction Spiral bevel gear noise does not always mean there is a manufacturing problem. A new assembly, shim adjustment, bearing change, shaft-position shift, or even a difference between expected and actual load conditions can alter the contact pattern, backlash, or mounting condition and change how the gear set sounds. A more useful approach is to […]

Gear Milling vs Gear Hobbing: Which Fits Your Gear Project?

Gear Milling vs Gear Hobbing Which Fits Your Gear Project

Introduction Gear milling and hobbing are often compared as if one simply replaces the other. In practice, the drawing usually decides. A prototype with a shoulder close to the teeth may be easier to mill, while a standard external spur gear made in recurring batches may be a straightforward hobbing job. Quantity matters, but it […]

When Should a Bevel Gear Pair Be Inspected as a Matched Set?

When Should a Bevel Gear Pair Be Inspected as a Matched Set

Introduction Two bevel gears may pass dimensional and tooth-geometry inspection individually but still fail to achieve the expected backlash or contact condition after assembly. For some projects, individual inspection is sufficient. However, when acceptance depends on actual meshing performance, matched-set inspection becomes more important. The key question is not whether every bevel gear pair must […]

Internal Gears: Types, Applications, and Manufacturing

Internal Gears Types, Applications, and Manufacturing

Introduction Internal gears have teeth on the inside of a ring and mesh with an external gear or pinion. Compared with common external gears, this arrangement supports more compact layouts, making internal gears a common choice for planetary gear systems, compact reducers, and other space-limited transmissions. However, an internal gear is not simply a gear […]
